# My Experience in Building [Swagger Editor](http://editor.swagger.io)

Use arrow keys to navigate →
---

# About Me

<img width="100px" src="https://avatars2.githubusercontent.com/u/543633?v=3&s=460">
### Mohsen Azimi
#### Software Engineer @Apigee

* Github: [`@mohsen1`](https://github.com/mohsen1)
* Twitter: [`@mohsen____`](https://twitter.com/mohsen____)
* Website: [`azimi.me`](http://azimi.me)

---

# What is Swagger?

---

![Define Swagger](images/define-swagger.png)

---

# Swagger API
* #### API specification format

---

# Swagger API
* #### API specification format
* #### Tools for generating documentation (Swagger UI)

---

# Swagger API
* #### API specification format
* #### Tools for generating documentation (Swagger UI)
* #### Tools for generating API spec from the code (Swagger Core)

---

# Swagger API
* #### API specification format
* #### Tools for generating documentation (Swagger UI)
* #### Tools for generating API spec from the code (Swagger Core)
* #### Tools for consuming APIs in client side (SwaggerJS)
* #### Tools for generating server and client code from the specs
---

---

# Specs first or code first?

---

# Specs first or code first?

---

---

# Swagger 1.2
[http://petstore.swagger.io/api/api-docs](http://petstore.swagger.io/api/api-docs)
  ```json
apiVersion: "1.0.0",
swaggerVersion: "1.2",
  apis: [
    {
      path: "/pet",
      description: "Operations about pets"
    },
    {
      path: "/user",
      description: "Operations about user"
    },
    {
      path: "/store",
      description: "Operations about store"
    }
  ],
  authorizations: { ....
  ```

---
##### <code>pet.json</code>

```json
{
  "resourcePath": "/pet",
  "apis": [
    {
      "path": "/pet/findByTags",
      "operations": [
        {
          "method": "GET",
          "summary": "Finds Pets by tags",
          "responseMessages": [
            {
              "code": 400,
              "message": "Invalid tag value"
            }
          ]
        }
      ]
    },
    {
      "path": "/pet/{petId}",
      "operations": [
        {
          "method": "PATCH",
          ...
```

---
class: center, middle

# Swagger 2.0

---

# Swagger 2.0
* #### Single file for specification

---

# Swagger 2.0
* #### Single file for specification
* #### Tree view of the API

---

# Swagger 2.0
* #### Single file for specification
* #### Tree view of the API
* #### More JSON Schema

---

# Swagger 2.0
* #### Single file for specification
* #### Tree view of the API
* #### More JSON Schema
* #### Introduction of JSON References

---

# Swagger 2.0
* #### Single file for specification
* #### Tree view of the API
* #### More JSON Schema
* #### Introduction of JSON References
* #### Makrdown in descriptions

---

# Swagger 2.0
* #### Single file for specification
* #### Tree view of the API
* #### More JSON Schema
* #### Introduction of JSON References
* #### Makrdown in descriptions
* #### A JSON Hyper-Schema for validating Swagger 2.0 specs

---

---

#YAML for human
  ```yaml
swagger: '2.0'
info:
  version: 1.0.0
  title: A simple API
paths:
  /:
    get:
      responses:
        200:
          description: OK

```
---
# JSON for machine

```json
{
  "swagger": "2.0",
  "info": {
    "version": "1.0.0",
    "title": "A simple API"
  },
  "paths": {
    "/": {
      "get": {
        "responses": {
          "200": {
            "description": "OK"
          }
        }
      }
    }
  }
}
```

---

### How should you make an API?
<h1> </h1>
---

### How should you make ~~an API~~ <span style="color: red">anything</span>?
<h1> </h1>
---

### How should you make ~~an API~~ <span style="color: red">anything</span>?
<h1>Design it first!</h1>

---
# Design First API Development

* ### Fast feedback loop

---
# Design First API Development

* ### Fast feedback loop
* ### Well structured API

---

# Design First API Development

* ### Fast feedback loop
* ### Well structured API
* ### Collaborative development

---

# Design First API Development

* ### Fast feedback loop
* ### Well structured API
* ### Collaborative development
* ### Well documented API

---

# Design First API Development

* ### Fast feedback loop
* ### Well structured API
* ### Collaborative development
* ### Well documented API
* ### Testable API

---

### Good design is only possible with good tools

![Design Tools](images/design_tools.jpg)

---

# The case for an editor

---

# The case for an editor

* ### There was no tool for authoring Swagger specs with fast feedback loop

---

# The case for an editor

* ### There was no tool for authoring Swagger specs with fast feedback loop
* ### Nobody have all the Swagger specs on top of their head to write an accurate specs *
###

\* Not even [@webron](https://github.com/webron) or [@fehguy](https://github.com/fehguy)
---
# The case for an editor

* ### There was no tool for authoring Swagger specs with fast feedback loop
* ### Nobody have all the Swagger specs on top of their head to write an accurate specs *
* ### Other API specifications had authoring tools

\* Not even [@webron](https://github.com/webron) or [@fehguy](https://github.com/fehguy)

---

# Swagger Editor

<table class="lean" cellspacing="0">
  <tbody>
    <tr>
      <th>A tool to enable design-first API development</th>
      <th>Live documentations preview</th>
    </tr>
    <tr>
      <th>Semantic and Schema error reporter</th>
      <th>Syntactic error reporter</th>
    </tr>
    <tr>
      <th>Code storage (local storage or a backend)</th>
      <th>Import/Export Swagger specs in YAML and JSON</th>
    </tr>
    <tr>
      <th>Can be hooked to a backend</th>
      <th>Try operation</th>
    </tr>
    <tr>
      <th>Documentation/Code fold sync</th>
      <th>Code navigation</th>
    </tr>
    <tr>
      <th>Authentication support</th>
      <th>Tag navigation</th>
    </tr>
  </tbody>
</table>
---

# Starting the project and making choices

---

<img height="400px" src="images/yeoman.png">
# Started with Yoeman

---
class: center, middle

#AngularJS

---
class: center, middle

# Pure JavaScript

---

<img width="200" src="images/swagger.png">
#SwaggerUI for rendering (Initially)

---

#Ace for code editor

---
class: center, middle
<img height="200" src="images/grunt.png">
# Grunt for build tools
---
class: center, middle
<img src="images/jshint.png" width="300">
#JSHint
---
class: center, middle
<img src="images/jscs.png">
#JSCS
---

class: center, middle
<img height="200" src="images/github.png">
#Github for hosting the code and tracking issues

---

# Editor workflow

---
# Editor workflow

---

# Easy!

---

# Hacking it together

---

# It works!

---

---

---

---

# Challenges

* ### Render fast
* ### Keep typing smooth
* ### Report errors

---

# Challenges

* ### Render fast
* ### Keep typing smooth
* ### Report errors

---

# Rendering Fast

* ### Rendering is not fast! Specially if spec is large.

---

# Rendering Fast

* ### Rendering is not fast! Specially if spec is large.
* ### Throttling the render task is reasonable.

---

# Rendering Fast

* ### Rendering is not fast! Specially if spec is large.
* ### Throttling the render task is reasonable.
* ### AngularJS does not re-render entire HTML when scope changes partially, don't override the scope on each keypress

---

# Keeping typing experience smooth

* ### Throttling rendering task helps not blocking the UI while typing
---

# Keeping typing experience smooth

* ### Throttling rendering task helps not blocking the UI while typing
* ### Parsing YAML and walking the spec tree for validation is expensive, let's throttle those too
---

### A lot of tasks should run when user stops changing the spec (Error checking, rendering and saving)
### Each task can fail in it's own way

---

# Pub-Sub
#### Publish–subscribe pattern

---

# Pub-Sub

---

# Pub-Sub
* ### Each task(component) can emit an error

---

# Pub-Sub
* ### Each task(component) can emit an error
* ### Error reporter will show errors to user no matter which component they are coming from

---
# Pub-Sub
* ### Each task(component) can emit an error
* ### Error reporter will show errors to user no matter which component they are coming from
* ### One component keeps the state of all tasks success

---

# Change listening and change listeners

```js
Storage.addChangeListener('yaml', update);
```

```js
this.addChangeListener = function (key, fn) {
  if (angular.isFunction(fn)) {
    if (!changeListeners[key]) {
      changeListeners[key] = [];
    }
    changeListeners[key].push(fn);
  }
};
```
[see this in Github](https://github.com/swagger-api/swagger-editor/blob/master/app%2Fscripts%2Fservices%2Flocal-storage.js#L46-L53)

---

<img src="images/pub-sub.png" alt="" width="100%">
---

# Challenges revisited

* ### Render fast  <span style="color: green">✔</span>
* ### Keep typing smooth  <span style="color: green">✔</span>
* ### Report errors  <span style="color: green">✔</span>

---

# A new problem

---

# A new problem
## JSON does not care about property <b>order</b>, therefore Swagger operation and responses may lose their order during YAML→JSON conversion

---

# We need to sort object properties based on their position in YAML

---

# Some processors sort keys alphabetically
```yml
foo:
  jaz: 2
  bar: 1
```

```json
{
  "foo": {
    "bar": 1,
    "jaz": 2
  }
}
```

---

### To sort properties based on their position in the YAML we need an abstract syntax tree (AST) of the YAML

---

#### What is an AST?

---

```yml
foo:
  jaz: 2
  bar: 1
```

```yaml
value:
      value: "foo"
      start_mark:
        line: 0
        column: 0
      end_mark:
        line: 0
        column: 3
      value:
            value: "jaz"
            start_mark:
              line: 1
              column: 2
            end_mark:
              line: 1
              column: 5
            value: "2"
            start_mark:
              line: 1
              column: 7
            end_mark:
             ....

```

---
### Using an array instead of objects to keep the order

```yaml
/:
 get: ...
 post: ...
```

```js
{
  "post": { /* ... */ },
  "get": { /* ... */ }
}
```

```js
{
  "operations": [
    {
      "operationsName": "get", /* ... */
    },
    {
      "operationsName": "post", /* ... */
    }
  ]
}
```

---

## Sorting object keys

---

#### Complete workflow

---

# AST can do much more

* ### Points to exactly where an error occurred (Jump to line)

---

# AST can do much more

* ### Points to exactly where an error occurred (Jump to line)
* ### Points to exactly where a path, operation or parameter is located in code (Jump to YAML)

---

# AST can do much more

* ### Points to exactly where an error occurred (Jump to line)
* ### Points to exactly where a path, operation or parameter is located in code (Jump to YAML)
* ### Brings into the view the operation that is being edited currently

---

## Jump to line link when there is a YAML syntax error
<img src="images/error-line.png" width="100%">

---

# From YAML syntax error to line number

YAML syntax error gives back the line number and column number

```json
problem_mark:
  buffer: "swagger: '2.0'↵info:↵ version: 1.0.0↵   title: '..."
  column: 8
  line: 3
  pointer: 46
```
---

# Easy!

---

# Jump to line link when there is an error in Swagger spec

---

# Swagger errors are JSON Schema errors

### JSON Schema errors have:
#### Line number in JSON
#### JSON path to error

---

# Line number in JSON is useless!

---

### Getting the line number from a JSON path

---

# AST walker

* ### In-order tree walking

---

# AST walker

* ### In-order tree walking
* ### Very cheap operation

---

# AST walker

* ### In-order tree walking
* ### Very cheap operation
* ### We need to update the AST when spec changes

---

# Auto-completion

* ### We needs to know possible keywords for current point (row, col)

---

# Auto-completion

* ### We needs to know possible keywords for current point (row, col)
* ### Scanning the AST will give us where in the Swagger tree are we

---

# Scanning the AST

* ### Breadth first search (BFS)

---

# Scanning the AST

* ### Breadth first search (BFS)
* ### Expensive operation

---

# Scanning the AST

* ### Breadth first search (BFS)
* ### Expensive operation
* ### Should fail gracefully

---

# Providing suggestions based on JSON Path

* ### A secondary tree that has list of possible keywords (Keyword map)

---

# Providing suggestions based on JSON Path

* ### A secondary tree that has list of possible keywords (Keyword map)
* ### Walk the keyword map with that path and return all possible keywords

---

# Providing suggestions based on JSON Path

* ### A secondary tree that has list of possible keywords (Keyword map)
* ### Walk the keyword map with that path and return all possible keywords
* ### Keyword map can be extended with vendor extensions

---

# Swagger Editor keyword map

```json
{
    swagger: String,
    info: {
        version: String,
        title: String,
        description: String,
        termsOfService: String,
        contact: {
            name: String,
            url: String,
            email: String
        },
        license: {
            name: String,
            url: String
        }
    }
}
```
---

# Try this Operation

<img src="images/try.png" alt="" width="100%">
---

# Try this Operation

* ## Request preview (body and URL)

---

# Try this Operation

* ## Request preview (body and URL)
* ## Form for parameters and request body

---

# Try this Operation

* ## Request preview (body and URL)
* ## Form for parameters and request body
* ## Response preview (Raw, Pretty and Rendered)

---

### Making the form

---

# CORS

* ### It's a big problem

---

# CORS

* ### It's a big problem
* ### Online Swagger Editor is a web application

---

# CORS

* ### It's a big problem
* ### Online Swagger Editor is a web application
* ### There is no way to know if a request failed because of cross-origin policy

---

# Moving out the client logic

* ### UI should not make the calls

---

# Moving out the client logic

* ### UI should not make the calls
* ### JSON Schema generation should be it's own module

---

# Moving out the client logic

* ### UI should not make the calls
* ### JSON Schema generation should be it's own module
* ### A stand-alone "Swagger Client"

---

# Modules made for Swagger Editor

---

# [`_.applyDiff`](https://github.com/mohsen1/apply-diff)

* ## Updates an object deeply
* ## Avoids any unnecessary overrides
* ## Available as Lodash/Underscore plugin

---

# [JSON Formatter](https://github.com/mohsen1/json-formatter)

<img src="https://github.com/mohsen1/json-formatter/raw/master/screenshot.png" alt="">
---

# [JSON Formatter](https://github.com/mohsen1/json-formatter)

* ## Angular directive for collapsible JSON in HTML
* ## Available in Bower for AngularJS apps
* ## Very popular (70 Github Stars)

---

# [Angular JSON Schema Form](https://github.com/mohsen1/angular-json-schema-form)

* ## Generate forms from JSON Schema
* ## `ng-model` compatible
* ## Available in Bower

---

# [JSON Schema View](https://github.com/mohsen1/json-schema-view)

<img src="https://github.com/mohsen1/json-schema-view/raw/master/images/screenshot.png?raw=true" alt="">
---

# [JSON Schema View](https://github.com/mohsen1/json-schema-view)

* ## Similar to JSON Formatter
* ## Renders JSON Schema in a nice collapsible format
* ## AngularJS Directive available in Bower

---

# [CORS it!](https://github.com/mohsen1/cors-it)

* ## Tiny Node.js app for proxying cross-origin calls
* ## Used to make it possible to import specs from anywhere in the online editor
* ## Available in npm

---

# [AngularJS Directive Yoeman Generator](https://github.com/mohsen1/generator-angular-directive)

* ### Uses [Bower Publishable Angular Directive Boilerplate](https://github.com/mohsen1/angular-directive-boilerplate)
* ### Easily bootstrap an AngularJS directive that can be published to the world
* ### Project structure, build tools and tests

---

# Questions?
